Parameters:
Reading cuvette | 800 Tests/hour,1200Tests/hour with ISE(Optional) |
Incubating Positions | 20 incubating Positions |
Photometric System
| Light source:6V,10W long life halogen lamp |
Filters:340/405/450/510/546/578/630nm, 2 more open filter positions | |
Wavelength accuracy:±2nm | |
Measuring System
| Measuring range:0-3.600O.D. |
Photometric linearity:±2% from 0 to 2.500 O.D. | |
Photometric accuracy:±2% from 0 to 2.500 O.D. | |
Drift<0.005 O.D. | |
Incubator Temperature | R.T.25℃,30℃,37℃ |
Control | Precision:±0.1℃ |
Display | Touch Screen |
Printer | Built-in thermal printer |
Interface | RS-232,USB |
Power Supply | AC110/220V±10%,60/50Hz |
External Size(W*D*H) | 400*380*200mm |
Package Size(W*D*H) | 500*530*350mm |
Gross Weight | 12kg |
